PT801P
- Specification
OPTICS
Source: Philips Platinum 35ST, 800W
CT: 6000K
Life: 750H
MOVEMENT
Pan movement: 540°/630°optional (16 bit)
Tilt movement: 270° (16 bit)
Advanced motion system: auto repositioning, fast, quiet and smooth
COLORS
CMY color mixing
CTO linear 2700K - 6500K
1 Color wheel: 8 dichroic filters + open
GOBOS
1 Rotating gobo wheels: 6 interchangeable + open
1 Static gobo wheel: 3 gobos + animation wheel + open
FEATURES
Rotating prism: 3 facet prism
Focus
Iris
Shutter: mechanical, variable from 1-25Hz or random
Dimmer: 0%-100% linear dimming
Frost: 0 - 100%
Zoom: 8°- 50°linear zoom
Patented framing system: full field travel with the ability to create different shapes. Framing rotation of 90°
DISPLAY
Battery operated for fast addressing
15 second standby auto lock
Pan/ Tilt disengage (hold MENU and ENTER button)
SOFTWARE
Upgrades: fast and convenient using uploader over DMX
Remote reset DMX address, lamp control, fixture reset, sound control by DMX
Run time of lamp and fixture
3 Control channel modes: 38/36/59 channels
OTHER SPEC
Input signal isolation
Auto thermal protection circuit
Optional installed wireless receiver
RDM compatible
POWER
AC100-240V, 50/60HZ
DIMENSIONS AND WEIGHT
Packing dimension: 83.5 x 56 x 48.5 cm
Net weight: 41.5kgs
Gross weight: 48.5kgs
Source: Philips Platinum 35ST, 800W
CT: 6000K
Life: 750H
MOVEMENT
Pan movement: 540°/630°optional (16 bit)
Tilt movement: 270° (16 bit)
Advanced motion system: auto repositioning, fast, quiet and smooth
COLORS
CMY color mixing
CTO linear 2700K - 6500K
1 Color wheel: 8 dichroic filters + open
GOBOS
1 Rotating gobo wheels: 6 interchangeable + open
1 Static gobo wheel: 3 gobos + animation wheel + open
FEATURES
Rotating prism: 3 facet prism
Focus
Iris
Shutter: mechanical, variable from 1-25Hz or random
Dimmer: 0%-100% linear dimming
Frost: 0 - 100%
Zoom: 8°- 50°linear zoom
Patented framing system: full field travel with the ability to create different shapes. Framing rotation of 90°
DISPLAY
Battery operated for fast addressing
15 second standby auto lock
Pan/ Tilt disengage (hold MENU and ENTER button)
SOFTWARE
Upgrades: fast and convenient using uploader over DMX
Remote reset DMX address, lamp control, fixture reset, sound control by DMX
Run time of lamp and fixture
3 Control channel modes: 38/36/59 channels
OTHER SPEC
Input signal isolation
Auto thermal protection circuit
Optional installed wireless receiver
RDM compatible
POWER
AC100-240V, 50/60HZ
DIMENSIONS AND WEIGHT
Packing dimension: 83.5 x 56 x 48.5 cm
Net weight: 41.5kgs
Gross weight: 48.5kgs
Errors and omissions are possible. All specifications are subject for change without prior notice.
