Optical system
Source: 1200W white LED
Fixture CT: 6500K
"LED life expectancy：20000 hours  Average Light Source Life*
*Testing conditions in the lab may differ based on various factors."
CRI: Ra≥70 (Optional Ra90)
Fixture output: 40000lm

Movement
Pan:540° (16 bit)
Tilt: 270° (16 bit)
Auto pan/tilt repositioning

Color system
CMY+CTO color mixing
1 Color wheel: 6 dichroic filters+open

Gobo system
2 Rotating gobo wheel: each with 7 interchangeable gobos+ open
1 Animation wheel

Effects
Motorized focus
Zoom range：4.5°-55°
Auto focus
2 Rotating prisms: 4-facet liner prism + 4-facet circular prism, used only or overlap, indexable, rotating in both directions
Frost: light, medium, light+medium
4 individually positionable blades with ±120°rotation of the complete framing system
Iris：5%-100% open
Dimming：0-100% linear dimming
Strobe: electronic, variable from 1-25Hz or pulse

Protection rating
IP66

Display
LCD Display
Pan/tilt disengage (hold Left and Right buttons), support to complete the reset detection in the flight case

Software
Upgrade with DMX
Run time of fixture and light source
2 Control channel modes: 43/65CH
Auto thermal protection

Control
Input signal isolation
Optional wireless DMX
Optional Art-Net Control
Optional RDM protocol

Electric parameter
AC100-240V, 50/60Hz
Power consumption: 1400W

Dimension and weight
Product dimension: 444x315x679mm
Packing dimension (carton): 810x550x430mm
Net weight：34 kg
Gross weight (carton)：39 kg
